Technical Specifications | ||
Parameters | Range | Accuracy |
CO2 | 0 -15% |
±(0.2%+5% )@0-10% ±(0.2%+8% )@10-15% |
RR | -150bpm | ±1bpm |
N2O | 0 -100 | ±(2%+3% of reading) |
Sevoflurane | 0 -10% |
±(0.15% + 5% of reading)@0-5% ±(0.3% + 10% of reading)@5-10% |
Isoflurane | 0 -8% |
±(0.15% + 5% of reading)@0-5% ±(0.3% + 5% of reading)@5-8% |
Enflurane | 0 -8% |
±(0.15% + 5% of reading)@0-5% ±(0.3% + 5% of reading)@5-8% |
Halothane | 0 -8% |
±(0.15% + 5% of reading)@0-5% ±(0.3% + 5% of reading)@5-8% |
Desflurane | 0 -22% |
±(0.15% + 5% of reading)@0-10% ±(0.3% + 10% of reading)@10-22% |
Environmental | |
Operating temperature | 0 to 40 ºC |
Operating atmospheric pressure | 70 to 120 kPa |
Operating humidity | 10-95%, non-condensing |
Storage temperature | -20 to 70 ºC |
Storage atmospheric pressure | 50 to 120 kPa |
Physical Characteristics | |
Dimensions | 48×24.3×32.8mm |
Weight | 28g (not include cable) |
Others | |
Water Resistance | IPX4– Splash-proof (sensor head only) |
Warm up time | 15s |
Adult airway adapter | Dead Space ≤ 6ml |
Infant airway adapter | Dead Space ≤ 1ml |
